Product features (Đặc tính sản phẩm)
- It supports COE (CANopen over EtherCAT) protocol, complies with CiA402 standard, supports 32 axes, and supports the master station with standard EtherCAT protocol. The communication cycle between the master station and the slave station can reach 32 axes for 1ms.
- The network cable connection replaces the traditional pulse direction signal cable, and is equipped with power cable and encoder cable, with simple wiring. It can greatly reduce cable cost, labor cost and maintenance cost.
- Relying on the low bus load of EtherCAT bus and the point-to-point physical layer, it can greatly suppress the generation of interference and clutter, and significantly improve the reliability and anti-interference ability of the system.
- EtherCAT bus technology combined with the latest control algorithm has greatly improved the performance.
- 7-channel signal input and 7-channel signal output are configured, which can be used for probe input, positive and negative limit, origin input, alarm output, in place output, holding brake signal output and other functions to meet the needs of different customer groups.
- Using encoder as position feedback, the position deviation can be compensated in real time, which fundamentally solves the problem of step loss of traditional stepping motor.
- The current can be adjusted in real time according to the load and speed, which makes the operation more stable and the motor heating lower.
