Product features (Đặc tính sản phẩm)
- Medium sized PLC has powerful function, strong applicability and larger storage space.
- The program capacity is 16MB and the speed is 5-6 times that of XG1.
- It supports the function of EtnerCAT bus and can control the synchronous movement of 32 axes servo motor.
- It supports 4-channel high-speed pulse output and 4-channel 200kHz differential input high-speed counting.
- Support motion control commands such as interpolation and follow-up.
- It supports NPN and differential signal input, transistor output and DC24V power supply.
- Up to 16 expansion modules can be connected externally.
- Support PID, external interrupt, C function block, basic logic control and data operation.
- Support Ethernet communication, MODBUS communication and other functions.
- With clock and data power down holding function.
